40m/Min Thick Plate Steel Cnc Turret Punch Press Machine

Name: 40mMin Thick Plate Steel Cnc Turret Punch Press Machine
Brand: PUHUA
Price: 1 USD

Quality 40m/Min Thick Plate Steel Cnc Turret Punch Press Machine wholesale

Brand Name : PUHUA

Model Number : AMD-HB

Certification : CE ISO

Place of Origin : CHINA SHANDONG

MOQ : 1 set

Payment Terms : L/C, T/T

Supply Ability : 50+SETS+per year

Delivery Time : 20-40 workdays

Packaging Details : Stretch film

type : cnc punching machine

Warranty : One Year

Power Source : electric

Application : sheet metal punching

color : customizable

power : customizable

Contact Now

40m/Min Thick Plate Steel Cnc Turret Punch Press Machine

Main Features

•Using in-line type die set which researched and developed by our company, matching with thick plate stamping dedicated mould, the processing sheet thickness can up to 16mm;

•Equipped with high precision hydraulic main transmission system, speed is faster, stroke is adjustable;

•Adopts Siemens CNC special system and match up digital AC servo motor to make it faster and reliable, operation is easy, no need manual programming and processing, with the second positioning function, can achieve no dead zone processing;

•Equipped with concentrated lubricating device, reduce each kinematic pair friction, improve machine service life.

40m/Min Thick Plate Steel Cnc Turret Punch Press Machine

Type	AMD-HB40	AMD-HB50	AMD-HB60	AMD-HB80	AMD-OHB80	AMD-OHB100	AMD-OHB120	AMD-OHB160
Punch force	40T	50T	60T	80T	80T	100T	120T	160T
Machine structure	open type				closed type
Max.Processing thickness	35mm
Working Range	1500800mm/30001600mm
Clamp amount	2-3pcs
Punching frequency	120HPM		80HPM		80HPM	80HPM	80HPM	60HPM
Turret speed	≤40m/min
Processing precision	±0.15mm
Air Ventilation	0.1m³/min
Air pressure	0.5MPa(5.0kgf/cm²)
Power	380V±5%/50HZ
Number of stations in turret	3-12pcs(Optional)

40m/Min Thick Plate Steel Cnc Turret Punch Press Machine
